According to DIN ISO 2768-1
General tolerance ISO 2768 does not specify where to use these tolerances. Tolerance class is defined as per design requirements and manufacturing capability. For example: for sheet metal parts ISO 2768–mk is used. And for machined components ISO 2768–fh can be used. ISO 2768-2: 1989, General tolerances — Part 2. If general tolerances according to ISO 2768-1 are valid, the following has to be inserted in the title box, i.e. For tolerance class medium. ISO 2768 – m or general tolerance ISO 2768 – m. For new designs only the general tolerance according to DIN ISO 2768-1 should be valid.
According to DIN ISO 2768-2
General Tolerances to DIN ISO 2768. The latest DIN standard sheet version applies to all parts made to DIN standards. Variations on dimensions without tolerance values are according to 'DIN ISO 2768- mk'. GENERAL TOLERANCES FOR LINEAR AND ANGULAR DIMENSIONS (DIN ISO 2768 T1) LINEAR DIMENSIONS.
General tolerances for linear measures and level squares with four tolerance classes are useful for simplifying drawings.
By choosing the tolerance class precision levels common in workshops should be taken into account.
If smaller tolerances are needed or bigger ones are more economical,
then these tolerances are indicated next to the nominal size.
Tabular 1 Limits for linear measures
Tolerance- class | Limits in mm for nominal sizes in mm | |||||||
0,5 to 3 | above | above 6 to 30 | above 30 to 120 | above 120 to 400 | above 400 | above 1000 | above 2000 | |
f (fine) | ± 0,05 | ± 0,05 | ± 0,1 | ± 0,15 | ± 0,2 | ± 0,3 | ± 0,5 | - |
m (medium) | ± 0,1 | ± 0,1 | ± 0,2 | ± 0,3 | ± 0,5 | ± 0,8 | ± 1,2 | ± 2 |
c (coarse) | ± 0,15 | ± 0,2 | ± 0,5 | ± 0,8 | ± 1,2 | ± 2 | ± 3 | ± 4 |
v (very coarce grob) | - | ± 0,5 | ± 1 | ± 1,5 | ± 2,5 | ± 4 | ± 6 | ± 8 |
For nominal sizes below 0,5 mm the limit measures are to be indicated directly at the nominal measure.
Jul 24, 2020 Part 1: General Tolerances ISO 2768-1. ISO 2768-1 is intended to simplify drawing indications and specifies general tolerances in 4 tolerance classes (f – fine, m – medium, c – coarse, v – very coarse). It applies for the linear dimensions and angular dimensions such as external sizes, internal sizes, step sizes, diameters, radii. 'ISO 2768 invokes a set of general tolerances based on a study of common machine shop practices. If the part does not meet these general tolerances, the part might still be accepted if it seems to work in its' function.
Tabular 2 Limit measures for radius of curvature and chamfer height
Tolerance class | Limits in mm for nominal sizes in mm | ||
0,5 to 3 | above 3 to 6 | above 6 | |
f (finne) | ± 0,2 | ± 0,5 | ± 1 |
m (medium) | |||
c (coarse) | ± 0,4 | ± 1 | ± 2 |
v (very coarse) |
Bei Nennmassen unter 0,5 mm sind die Grenzabmasse direkt am Nennmass anzugeben.
Tabelle 3 Grenzabmasse für Winkelmasse
Tolerance class | Limits in mm for nominal sizes in mm | ||||
to 10 | above 10 to 50 | above 50 to 120 | above 50 to 400 | above 400 | |
f (fine) | ± 1 ° | ± 30 ' | ± 20 ' | ± 10 ' | ± 5 ' |
m (medium) | |||||
c (coarse ) | ± 1 ° 30 ' | ± 1 ° | ± 30 ' | ± 15 ' | ± 10 ' |
v (very coarce) | ± 3 ° | ± 2 ° | ± 1 ° | ± 30 ' | ± 20 ' |
For nominal sizes below 0,5 mm the limit measures are to be indicated directly at the nominal measure. If general tolerances according to ISO 2768-1 are valid,
the following has to be inserted in the title box, i.e. for tolerance class medium
ISO 2768 – m or general tolerance ISO 2768 – m
For new designs only the general tolerance according to DIN ISO 2768-1 should be valid. The limit measurements of the tolerance classes m and f of DIN ISO 2768-1 are identic with those of DIN 7168-1.
According to DIN ISO 2768-2
Cached
DIN ISO 2768-2 is for simplifying drawing and fixes general tolerances in three tolerance classes for form and position.
By choosing a special tolerance class exactly the precision level common in workshops should be taken into account.
Iso 2768 Hole Tolerances - Nitrosociety
If smaller tolerances are needed or bigger are more economical these tolerances should be mentioned directly according to ISO 1101.
Iso 2768 Hole Tolerances - Wondersupernal
General tolerances for form and position should be used while the tolerance principle according. to ISO 8015 is valid and while this is mentioned in the drawing.
This tolerance principles says that no opposite relation between measure, form and position tolerance exists (principle of superposition).
Tolerance class | General tolerances for straightness and evenness in mm | |||||
Range of specified size in mm | ||||||
to 10 | above 10 to 30 | above 30 to 100 | above 100 to 300 | above 300 to 1000 | above 1000 to 3000 | |
H | 0,02 | 0,05 | 0,1 | 0,2 | 0,3 | 0,4 |
K | 0,05 | 0,1 | 0,2 | 0,4 | 0,6 | 0,8 |
L | 0,1 | 0,2 | 0,4 | 0,8 | 1,2 | 1,6 |
Tolerance class | General tolerances for straightness and evenness in mm | |||||
Range of specified size in mm | ||||||
to 100 | above 100 to 300 | above 300 to 1000 | above 1000 to 3000 | |||
H | 0,2 | 0,3 | 0,4 | 0,5 | ||
K | 0,4 | 0,6 | 0,8 | 1 | ||
L | 0,6 | 1 | 1,5 | 2 | ||
Tolerance class | General tolerances for symmetry | |||||
Range of specified size in mm | ||||||
to 100 | above 100 to 300 | above 300 to 1000 | above 1000 to 3000 | |||
H | 0,5 | |||||
K | 0,6 | 0,8 | 1 | |||
L | 0,6 | 1 | 1,5 | 2 |
General tolerances for form and position are valid for form elements for which form and position tolerances are not indicated individually.
They are applicable for all characteristics of the form elements accept cylinders, profiles of any line or surfaces, inclines, coaxiality, position and total movement.
